Linear regression is a parametric regression method that is used to estimate real-valued outputs given real-valued input vectors. In this post, mean squared error is used as a loss function and gradient descent (or batched gradient descent) is used to learn parameters.

The computation graph below shows how linear regression works. The dot product of each input, a vector \(\vec{x}\) of size \(D\), and weight vector \(\vec{w}\) transposed is taken to produce the output \(h(x)\). The loss is then calculated by calculating the mean squared error using \(y\) and output \(h(x)\).

The bias term \(\beta\) is ignored for the purposes of this post, but can easily be appended to weight vector \(\vec{w}\) after appending a \(1\) to an input vector \(\vec{x}\).

Learning

Given a data set \(X\) of size \(N\) with \(D\) dimensions, parameters \(w\) must be learned that minimize our loss function \(L_{MSE}(y, \hat{y})\). The weight vector is learned using gradient descent. The derivation for term \(\frac{\partial L}{\partial w}\) in the weight update is displayed in the derivations section of this post.

\[ \begin{aligned} h(x) &= w^T \cdot x & \text{[Prediction]}\\ L_{\text{MSE}}(y, \hat{y}) &= \frac{1}{N}\sum^N_{i=1} (y-\hat{y})^2 &\text{[Mean squared error]}\\ w_i &= w_i - \alpha \frac{\partial L}{\partial w_i} & \text{[Weight update]}\\ &= w_i - \alpha \left[x_i(y - h(x))\right] &\\ w_i &= w_i - \alpha \frac{1}{B}\sum^{B}_{j=1} x_{j,i} (y-h(x)) & \text{[Batch weight update]}\\ \end{aligned} \]

Code

from typing import List
from tqdm import trange
import torch


def MeanSquaredError(y: torch.Tensor, yhat: torch.Tensor) -> float:
    """ Calculate mean squared error rate

    Args:
        y: true labels
        yhat: predicted labels

    Returns:
        mean squared error
    """

    return torch.sum((y - yhat)**2) / y.shape[0]


class LinearRegressor:


    def __init__(self) -> None:
        """ Instantiate linear regressor
        """

        self.w = None
        self.calcError = MeanSquaredError


    def fit(self, x: torch.Tensor, y: torch.Tensor, alpha: float=0.00001, epochs: int=1000, batch: int=32) -> None:
        """ Fit logistic regression classifier to data set

        Args:
            x: input data
            y: input labels
            alpha: alpha parameter for weight update
            epochs: number of epochs to train
            batch: size of batches for training
        """

        self.w = torch.zeros((1, x.shape[1]))

        epochs = trange(epochs, desc='Error')
        for epoch in epochs:

            start, end = 0, batch
            for b in range((x.shape[0]//batch)+1):
                hx = self.predict(x[start:end])
                dw = self.calcGradient(x[start:end], y[start:end], hx)
                self.w = self.w - (alpha * dw)
                start += batch
                end += batch

            hx = self.predict(x)
            error = self.calcError(y, hx)
            epochs.set_description('MSE: %.4f' % error)


    def predict(self, x: torch.Tensor) -> torch.Tensor:
        """ Predict output values

        Args:
            x: input data

        Returns:
            regression output for each member of input
        """


        return torch.einsum('ij,kj->i', x, self.w)


    def calcGradient(self, x: torch.Tensor, y: torch.tensor, hx: torch.Tensor) -> torch.Tensor:
        """ Calculate weight gradient

        Args:
            x: input data
            y: input labels
            hx: predicted output

        Returns:
            tensor of gradient values the same size as weights
        """

        return torch.einsum('ij,i->j', -x, (y - hx)) / x.shape[0]

Derivations

Derivative of loss function \(L\) with respect to the regression output \(h(x)\):
